Night Vision Fusion Thermal Imaging Goggles

$5,879.00 USD $6,599.00 USD Save $720.00 USD
Shipping calculated at checkout.
Quantity

Lead time 7 days

1 Year Warranty

Payment Protact

Well Packed

This night vision goggles fusion the thermal imaging mold, it is more stable than a clip on thermal imaging, both function operated seperately, it is the highest cost effective fusion night vision in the world market.

Main Features:

1.All metal housing, with excellent performance, small size, light weight;
2. Eyepiece spacing adjustable and we achieved Flip up down ON/OFF;
3. Optional configuration: night vision video output, Wifi transmission can be achieved through Wifi signal transmitter;
4. The magnification can be changed by changing the objective lens (or connecting the multiplier lens)
5. Built-in IR , adjusting the light spot size;
6. In the auto mode, the IR is adjusted by environment brightness;
7. Thermal imaging function is easy to use , one-button switch, easy to operate;
8. Various thermal imaging modes, thermal imaging covers the full screen;
9. Built-in indicator light, prompt switch position function, low power indicator light keeps blinking;
10. Can be upgraded to low-light thermal fusion version with video output.

Image intensifier tube
Size 36.7×31mm
Resolution(lp/mm) 64-67
Photocathode S25
SN(dB) 23-25
Sensitivity 2850K(uA/lm) 600
MTTF 10000h
Phosphor P43
Useful diameter 17.5mm
Weight(max) 75g
Electric
Auto function Filp up/down
Battery type AA
Voltage range 2.6-4.2V
Switch model ON/IR/AUTO
Working time 60-100h
IR illuminator 850nm 20mW
IR indicator Yes
Low battery indicator Yes
Optical & Structure
FOV 40°±2
Magnification 1X
Optical system F1.2 25mm
Optical distortion 2% Max
Focus range(M) 0.25–∞
IPD range 60-70mm
IPD lock type Manual
Size 115x127x69mm
Weight 468g
Thermal imaging module parameters
Type of sensor Unrefrigerated infrared thermal
Detector resolution 384×288
Applicable wavelength 8-12um
Objective lens focal length fixed-focus
Objective aperture F1.0
Brightness  Adjustable
 Focusing distance 250mm–∞
Image mode White heat / black heat / green bottom / red / hook edge
