LDTI006 50Hz Thermal Imaging Monocular with Laser Rangefinder, <40mK NETD, Waterproof & Mountable

The LDTI006 is a compact 3-in-1 thermal imaging device that combines a high-sensitivity thermal camera, a pulse laser rangefinder, and a red dot sight in a single lightweight unit.

Equipped with a 320 × 240 thermal sensor, <40 mK NETD sensitivity, and a smooth 50 Hz refresh rate, it provides clear and responsive thermal images for hunting, wildlife observation, search and rescue, security patrols, and other outdoor applications.

The integrated laser rangefinder measures distances up to 1,200 meters on buildings with an accuracy of ±1 meter. Weighing only 275 g without the battery, the LDTI006 can be used as a handheld thermal viewer or mounted on a standard 20 mm rail.

Main Features

1. 3-in-1 integrated design: combines thermal imaging, pulse laser ranging, and a red dot sight in one compact device.
2. 320 × 240 thermal sensor: provides detailed thermal images for observation in darkness, fog, smoke, and challenging lighting conditions.
3. <40 mK thermal sensitivity: detects small temperature differences and improves target visibility against complex backgrounds.
4. 50 Hz refresh rate: delivers smooth real-time imaging when scanning or following moving targets.
5. Long-range laser measurement: supports ranging distances of up to 1,200 m on buildings and at least 800 m in forest environments.
6. ±1 m ranging accuracy: pulse Time-of-Flight technology provides fast and reliable distance measurements.
7. Multiple viewing options: 1×, 2×, 4×, and 8× digital magnification help users inspect targets at different distances.
8. 15 color palettes: includes White Hot, Black Hot, Red Hot, Rainbow, and additional image modes for different environments.
9. Lightweight and compact: the 275 g body reduces carrying weight during extended outdoor use.
10. Flexible installation: suitable for handheld use or mounting through the integrated standard 20 mm rail base.
11. IP65 protection: resistant to dust and water spray for reliable operation in demanding outdoor environments.

Technical Specifications

Package Contents

• LDTI006 thermal imaging device × 1
• 18350 rechargeable battery × 1
• USB charging cable × 1
• User manual × 1
• Carrying case × 1
• Lens cleaning cloth × 1
